10 ton Crawler Grabber Warehouse Hydraulic Material Handling Equipment YGSZ100

10 ton Crawler Grabber Warehouse Hydraulic Material Handling Equipment YGSZ100
  • Enquiry Now!

    1.Product Introduction

    1. The power system is driven by an engine or a three-phase motor, which is flexible and flexible. Driven by electric motor, it has low maintenance cost, no pollution and low failure rate. Motor operation is one-third of the cost of engine operation;
    2. The electrical system has protection functions such as overcurrent, overload and leakage;
    3. Double pump double circuit total power regulation, negative flow control open system, reasonable allocation and utilization of motor power;
    4. Double pump combined flow and multi-action compound to improve work efficiency;
    5. Normally open rotary and travel brake. Independent oil cooling system, hydraulic oil cooler has large heat dissipation area and good heat dissipation effect;
    6. Italian hose, seal and Trelleborg cylinder seal, completely solve the hydraulic system does not seep;
    7. Enhanced working device for integral bending arm, gooseneck curved lever and various working grippers;
    8. The computer optimized design of the working device, the box structure to achieve a reasonable high-strength structure;
    9. Multi-function instrument panel, detecting various pressures, temperatures, oil levels and sound alarms;
    10. Three-dimensional air supply, fresh air circulation, fluorine-free environmental protection, large-capacity automatic heating and cooling air-conditioning system;
    11. Fixedly increased streamlined appearance driver’s cab, shockproof and soundproof, wide view, safe and comfortable, providing a car-like working environment;
    12. Optional rotary motor head makes the gripper have 360° rotation function, especially for directional materials, which has better gripping effect.


    Operating weightkg9600
     fuel consumptiong/kw.h≤210
    Fuel tank capacityL130
    Hydraulic systemMain pumpToshibaSA7V90
    Rated flowL/min170
    Working pressureMpa28
    Main valveToshibaZDF-18
    Hydraulic tank capacityL150
    Hydraulic motorTravelDOOSANTM09
    Performance parameterSwing speedrpm0-11
    Max. pulling force
    Travel speedKm/h0-4
    Max Gradient°28
    Ground pressurekpa42.2
    CabinOverall dimensionsmm1520x1000x1620
    swing supportOrbital diametermm800
    Four wheels and trackAdopts YC85series
    CylinderZhucheng longyuan oil cylinder, the south Korean technology import seal


     Main dimensions(mm)YGSZ100
      Upper full width (not including body foot pedal)2300
      Cabin width1000
      Cabin height2700
     Tail swing radius2050
    Balance weight distance from ground800
    Min.clearance to the ground390
    Guide pulley distance to driving wheel2300
    Track length2850
    Track inner distance1850
    Track pads width450
    Track outer distance with 450mm track2300
    Boom length4000
    Stick length2500
    Bucket Capacity0.25m³ 4 claws type
    Max. grabbing height5300
    Max. grabbing radius6670
    Grabbing radius at max grabbing height2820
    Max. grabbing depth2580
    Grabbing radius at deepest grabbing depth4445
